SFF Optical Transceiver 155M

Giới thiệu

Module Quang ZHT (SFF-155M) C-LINK Phân Phối

SFF Optical Transceiver 155M

Applications:

SDH STM-1

SONET OC-03

Fast Ethernet

ATM and Other Optical Data Transmission

Description:

SFF Transceiver is a high performance, cost effective module for serial telecom and datacom applications, all versions are compliant with SONET/SDH recommendations from OC-03 specifications. This module is designed for Single-Mode fiber and operates at the wavelength of 1310 nm. The transmitter section incorporates FP-LD and driver IC with temperature compensation and automatic power control circuit. The receiver section incorporates an efficient InGaAs/InP PIN photodiode and transimpedance with AGC for wide dynamic range. A LVPECL data interface simplifies interface to external circuitry. It is packaged in a small form factor multisourced 2X5 pin metal housing for excellent EMI shielding. The transceiver has excellent immunity and reliability.

Specifications

1. Small Form Factor 2X5 Pin Package

2. Duplex LC Connector,

3. 1310nm FP-LD Multi-Mode Transceiver

4. Driving up to 2km for Multi-Mode Optical Fiber

5. Compliant with ITU-T G. 957/958

6. Single +3.3V Power Supply, LVPECL Data Interface

7. Compliant with Telcordia GR-468-CORE

8. Class 1/1M Laser Product, Compliant with IEC825, FDA21 CFR1040.10 and CFR1040.11

9. Excellent EMI & ESD Protection

PN

Data Rate

Reach

Wavelength

Source

Output Power

Sensitivity

Application

SFF-SX-1

155Mb/s

2km

1310nm

FP

 -19~-10

≤-32

OC-3/STM-1/Fast Ethernet

SFF-LH-120

155Mb/s

20km

1310nm

FP

 -15~-8

≤-36

OC-3/STM-1/Fast Ethernet

SFF-LH-140

155Mb/s

40km

1310nm

FP

 -5~0

≤-36

OC-3/STM-1/Fast Ethernet

SFF-LH-180

155Mb/s

80km

1550nm

DFB

 -5~0

≤-36

OC-3/STM-1/Fast Ethernet
